will Renault Master fit in your garage?
Discover its dimensions in detail.
Renault Master Length, height, width, etc.
weight
| 3-seater panel van L1H1 | 3-seater panel van L2H2 | 3-seater panel van L4H3 | 3-seater Chassis Cab L3H1 | |
|---|---|---|---|---|
| Rear Wheels | Single Wheels | Single Wheels | Twin Wheels | Twin Wheels |
| Cargo volume | 8.0 M³ | 10.8 M³ | 17 M³ | N/A |
| Gross weight | 3.5T | 3.5T | 4.5T | 4.5T |
| Payload | 1,623 Kg | 1,529 Kg | 2,040 Kg | 2,435 Kg |
dimensions
| 3-seater panel van L1H1 | 3-seater panel van L2H2 | 3-seater panel van L4H3 | 3-seater Chassis Cab L3H1 | |
|---|---|---|---|---|
| Curb weight | 1,877 kg | 1,971 kg | 2,460 kg | 2,065 kg |
| Overall length | 5,075 mm | 5,575 mm | 6,875 mm | 6,220 mm |
| Wheelbase | 3,182 mm | 3,682 mm | 4,332 mm | 3,682 mm |
| Ground clearance | 182 mm | 174 mm | 167 mm | 166 mm |
| Inside loading length | 2,583 mm | 3,083 mm | 4,383 mm | N/A |
| Inside loading height | 1,700 mm | 1,894 mm | 2,048 mm | N/A |
| Inside loading width | 1,765 mm | 1,765 mm | 1,765 mm | N/A |
| Overall cargo length (min/max) | N/A | N/A | N/A | 3,734/4,275 mm |
| Sill height | N/A | N/A | N/A | 784 / 787 mm |
